SPESIFIKASI

The combination safety shower & eyewash unit saves space and fits easily into any work environment, allow workers to flush away hazardous substances that can cause injury. The shower valve operates quickly by a pull rod. The shower provides a superior washdown with a more even spray pattern. Eyewash is operated by a large, attractive push handle. Safe, steady water flow under varying water supply conditions from 0.2-0.8 MPa is assured by integral flow control valve assembly.

­Connect the unit to an uninterruptible water supply capable of delivering at 3 GPM when all components are operated simultaneously.
­A large area covered with water flows, at 60", the water pattern cover 20" in diameter.
­Easily located, accessible actuator no higher than 69".
­Center of the water pattern 16" from any obstructions.
­Valve actuators are easy to locate and readily accessible to users.
­Protects spray heads from airborne contaminants.
­The shower has a ball valve activates within one second.
­The eye wash has a hands-free stay-open valve activated within one second.
Controlled, low-velocity flow completely rinses eyes and face and is not injurious to the user.
­The shower can provide 76 liters of water per minute.
­The eye washer unit delivers 11.5 liters of water per minute.
­Protect spray heads from airborne contaminants.
­Material: 304 Stainless Steel
­Shower head/bowl: 304 Stainless Steel
­Shower Handle: Stainless Steel with safety yellow color ABS handle
­Spray head: ABS plastic single sprayer in safety yellow color
­Shower valve is making of 1" SS ball valve.
­Eye washer valve is making of 1/2"SS ball valve
­Pedestal: 304 Stainless Steel
­Foot treadle: 304 Stainless Steel
­Flow valve build in to avoid secondary hurt
­Water working pressure: 0.2MPa-0.8MPa
­Flow control: 76L/Min
­Standard approved: EN 15154-1:2006, EN 15154-2:2006, AS 4775:2007, ANSI/ISEA Z358.1-2014
­Gross weight: 17.5kg, Net weight: 15kg
­Dimension: 91cm*41cm*30cm
