EMERGENCY SHOWER
EMERGENCY SHOWER
ALS-ES100 Emergency Safety Shower & Eye Washer
SPESIFIKASI
The combination safety shower & eyewash unit saves space and fits easily into any work environment, allow workers to flush away hazardous substances that can cause injury. The shower valve operates quickly by a pull rod handle; the shower provides a uniform spray pattern to achieve excellent flushing. Eyewash operated by a large, attractive push handle. Safe, steady water flow under varying water supply conditions from 0.2-0.8 MPa is assured by integral flow control valve assembly.
Connect the unit to an uninterruptible water supply capable of delivering at 3 GPM when all components are operated simultaneously.
A large area covered with water flows, at 60", the water pattern cover 20" in diameter.
Easily located, accessible actuator no higher than 69".
Center of the water pattern 16" from any obstructions.
Valve actuators are easy to locate and readily accessible to users.
Protects spray heads from airborne contaminants.
The shower has a ball valve activates within one second.
The eye wash has a hands-free stay-open valve activated within one second.
Controlled, low-velocity flow completely rinses eyes and face and is not injurious to the user.
The shower can provide 76 liters of water per minute.
The eye washer unit delivers 11.5 liters of water per minute.
Protect spray heads from airborne contaminants.
Material: Galvanized steel with green epoxy coating.
Shower head/bowl: ABS plastic in safety yellow color.
Shower Handle: Stainless Steel with safety yellow color ABS handle.
Spray head: ABS plastic single sprayer in a safety yellow color
Shower valve is making of 1" SS ball valve
Eye washer valve is making of 1/2"SS ball valve
Pedestal: Aluminum Pedestal
Foot treadle: Cast Iron
Flow valve build-in to avoid secondary hurt
Water working pressure: 0.2MPa-0.8MPa
Flow control: 76L/Min
Standard approved: EN 15154-1:2006, EN 15154-2:2006, AS 4775:2007, ANSI/ISEA Z358.1-2014
Gross Weight: 16.5kg, Net Weight:14kg
Dimension: 91cm*41cm*30cm
